Pressure vessel head


Detailed mesh of the top of a pressure vessel including inlet and outlet nozzles. The fillets between the cylinder cap and the nozzles are modelled using the element filleting tools in Strand7. This tool automatically generates fillets between intersecting surfaces.


The stress plot identifies highly stressed areas.
